XT60/XT90 High-Current Connectors – Male / Female
New product
High-current XT60/XT90 connectors with gold-plated copper contacts for RC models, batteries and power electronics. Low contact resistance, secure connection and high-current capability. Available as separate male and female variants.
Choose variant
Lowest price in the last 30 days:
Shown according to the lowest price in the 30 days before the discount.
Product details
Professional XT60 and XT90 power connectors are designed for high-current applications where reliability and low losses are essential. Thanks to gold-plated copper contacts they offer excellent conductivity, low contact resistance and a long service life.
Insulation made from high-quality PA (polyamide) provides high heat resistance and safe operation even under demanding conditions. The connectors are ideal for RC models (cars, aircraft, drones), LiPo batteries, chargers, power systems and other high-power electronics.
Technical specifications:
- Contact material: gold-plated copper
- Insulation material: PA (polyamid)
- Rated current: 30A
- Peak current: 60A
- Rated voltage: 500V DC
- Contact resistance: 0.55 mΩ
- Operating temperature: -20 °C to +120 °C
- Recommended wire: approximately 2.05 mm - bare copper conductor only, without insulation (12 AWG ≈ 3.3 mm²)
- Dimensions: approx. 2.4 × 1.7 × 1 cm
Product variants:
- Male connector
- Female connector
➡️ Each type is sold as a separate variant; select the one you need.
